Battery Driven Trackless Transfer Cart Heavy Steel Structure For Factory Workshop Material Handling
| Place of Origin | China |
|---|---|
| Brand Name | MRT |
| Certification | CE |
| Model Number | KPW |
| Minimum Order Quantity | 1 |
| Price | USD 38300-49600/Set |
| Packaging Details | Large-sized double-layer PVC film packaging, small-sized non-sterilization wooden box packaging |
| Delivery Time | 25-50 Woiking Days |
| Payment Terms | L/C, T/T, D/P |
| Supply Ability | 20Sets/Month |
Product Details
| Main Body Material | Q355 Welded Steel Structure | Traveling Speed | 0‑20 M/min Stepless Speed |
|---|---|---|---|
| Ground Clearance | 50‑80 Mm | Max Climbing Degree | ≤5° |
| Battery Charging Time | 6‑8 Hours | Safety Accessories | Anti‑collision Device Emergency Stop Alarm Lamp |
| Surface Finish | Anti‑corrosion Spray Painting | Working Environment Temperature | -20℃ ~ 55℃ |
| Available Optional Parts | Lifting Mechanism Automatic Navigation Auto Charger | Warranty Period | 1 Year |
You can tick the products you need and communicate with us in the message board.
| SKU_ID | Product_Name_EN | Load_Capacity | Power_Supply | Running_Mode | Dimension_L_W_H | Running_Speed | Main_Material | Certification | MOQ | Price_USD | Lead_Time | Warranty | Application_Scenario | Customization_Support | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TC-70T-TR-001 | 70 Ton Battery Powered Trackless Electric Transfer Cart | 70 Ton | Lead-acid Battery | Trackless | 5000*2000*650 mm | 0-25 m/min (Adjustable) | Q235 Carbon Steel | CE, ISO9001 | 1 Set | $41600.00 | 15 Working Days | 2 Years | Factory internal heavy material transportation | Yes | |
| TC-80T-TR-002 | 80 Ton Lithium Battery Trackless Electric Transfer Trolley | 80 Ton | Lead-acid Battery | Trackless | 7500*2500*1100 mm | 0-25 m/min (Adjustable) | Q355 High Strength Steel | CE, ISO9001 | 1 Set | $45600.00 | 20 Working Days | 2 Years | Large mechanical workpiece handling and transfer | Yes | |
| TC-90T-TR-003 | 90 Ton Battery Operated Trackless Electric Flat Cart | 90 Ton | Lithium Battery | Trackless | 4000*1800*600 mm | 0-25 m/min (Adjustable) | Q235 Carbon Steel | CE, ISO9001 | 1 Set | $49600.00 | 12 Working Days | 2 Years | Industrial mold handling and turnover | Yes | |
| TC-60T-TR-004 | 60 Ton Heavy Duty Trackless Electric Transfer Cart | 60 Ton | Lithium Battery | Trackless | 6500*2200*8500 mm | 0-25 m/min (Adjustable) | Q355 High Strength Steel | CE, ISO9001 | 1 Set | $38300.00 | 25 Working Days | 2 Years | Steel structure and metal parts conveyance | Yes |
Product Description
Trackless Transfer Cart
Trackless platform vehicle is rail‑free heavy‑duty transfer equipment. Equipped with solid rubber wheels, it realizes omnidirectional movement and 360‑degree in‑situ rotation. Speed is infinitely adjustable 20‑30 m/min no‑load and 10‑20 m/min full‑load. With hydraulic lifting mechanism, it runs stably with easy operation and simple maintenance for transporting molds steel structures and heavy workpieces in factories.
product superiority
- Free from rail installation reducing site reconstruction cost
- Robust welded steel frame guarantees reliable operating performance
- High wear resistance solid PU tires protect workshop floor
- Omnidirectional movement and in‑situ rotation suit confined working areas
- Wireless remote and onboard joystick dual control for easy handling
- Equipped with emergency stop audible visual alarm and obstacle detection
- Lithium battery powered low noise operation for indoor and outdoor sites
- Platform dimension and load capacity available for custom configuration
main technical parameters
| Parameter | Specification |
|---|---|
| Model | BWP series customizable |
| Rated Load | 5‑50t |
| Platform Size | Custom |
| Height | 500‑900mm |
| Speed | 0‑25m/min no‑load 0‑20m/min full‑load |
| Steering | Omnidirectional zero turn |
| Power | Battery driven |
| Control | Remote and handheld pendant |
| Wheel | Polyurethane solid rubber |
| Safety | Emergency stop anti‑collision warning horn |
| Working Time | 4‑8h |
| Custom | Size lifting function optional |
application scenarios
- In-plant heavy cargo transportation
- Large machinery parts handling
- Industrial mold transfer and replacement
- Steel and metal structure conveying
- Foundry high-load material transport
- Workshop and warehouse cross-area logistics
- Production line material replenishment
- Industrial equipment moving and installation
Why choose us?
- Professional manufacturer, all equipment can be customized according to your working conditions
- Strict quality inspection before delivery, support CE certification
- Long warranty period and overseas technical guidance service
- Flexible trade terms: EXW, FOB, CIF, DDP available
- Support OEM & ODM solution design
Contact us and send your requirements of load, size and working environment, we will provide the most suitable transportation solution and formal quotation for you.
